Hexagon
Head Bolts |
| DIN
931 DIN 601 |
| |
| mm
|
| Thread
size |
M6 |
M8 |
M10 |
M12 |
M14 |
| K |
4 |
5.3 |
6.4 |
7.5 |
8.8 |
| S |
10 |
13 |
17 |
19 |
22 |
| L |
30-50 |
35-80 |
45-120 |
50-150 |
50-150 |
|
| |
| Thread
size |
M16 |
M18 |
M20 |
M22 |
M24 |
| K |
10 |
11.5 |
12.5 |
14 |
15 |
| S |
24 |
27 |
30 |
32 |
36 |
| L |
50-150 |
60-150 |
65-150 |
40-200 |
50-200 |
|
| |
|
Hexagon
Head Screws |
| DIN933
DIN558 |
| |
| mm
|
| Thread
size |
M5 |
M6 |
M8 |
M10 |
M12 |
M14 |
| K |
3.5 |
4 |
5.3 |
6.4 |
7.5 |
8.8 |
| S |
8 |
10 |
13 |
17 |
19 |
22 |
| L |
16-50 |
16-50 |
16-60 |
20-60 |
20-60 |
30-80 |
|
| |
| Thread
size |
M16 |
M18 |
M20 |
M22 |
M24 |
| K |
10 |
11.5 |
12.5 |
14 |
15 |
| S |
24 |
27 |
30 |
32 |
36 |
| L |
30-80 |
45-80 |
50-80 |
40-80 |
50-80 |
|
| |
|
Hex Bolts |
| ANSI/ASME
B18.2.1 1981 IFI C-10
(A-10)
|
| |
| inches
|
| THREAD
SIZE |
1/4 |
5/16 |
3/8 |
7/16 |
1/2 |
5/8 |
3/4 |
| THREAD
PER INCH |
20 |
18 |
16 |
14 |
13 |
11 |
10 |
| K1 |
11/64 |
7/32 |
1/4 |
13/64 |
11/32 |
27/64 |
1/2 |
| K2 |
5/32 |
13/64 |
15/64 |
9/32 |
5/16 |
25/64 |
15/32 |
| S |
7/16 |
1/2 |
9/16 |
5/8 |
3/4 |
15/16 |
11/8 |
| L |
1/2-4 |
5/8-4 |
3/4-4 |
7/8-4 |
1-4 |
11/4-6 |
11/2-6 |
|
